G e n e r a t o r

MJB SERIES 55-90 kVA

TECHNICAL S PECIF ICA TIONS

GENERATOR GROUP
MODEL MJB0055 MJB0070 MJB0072 MJB0088 MJB0090
kVA 55 70 72 88 90
Stand By Power
kW 44 56 57.6 70.4 72
kVA 50 63.6 65.5 80 81.8
Prime Power
kW 40 50.9 52.3 64 65.5
DIESEL ENGINE
BRAND BAUDOUIN
Model 4M06G55/5 4M10G70/5 4M11G70/5 4M10G88/5 4M11G90/5
Engine Power - Stand By kW 53 63 66 77 81
Engine Power - Prime kW 48 57 60 69 74
Engine Speed (rpm) 1500 1500 1500 1500 1500
Number of Cylinder 4 - In Line 4 - In Line 4 - In Line 4 - In Line 4 - In Line
Displacement (lt) 2.3 4.087 4.5 4.087 4.5
Bore x Stroke (mm) 89x92 105x118 105x130 105x118 105x130
Compression Rate 17.5:1 17.5:1 18:1 17.5:1 18:1
Governor Type ECU Electronic Electronic Electronic Electronic
Induction TurboCharged-Aftercooler TurboCharged TurboCharged TurboCharged TurboCharged 11
Combustion System Direct Injection Direct Injection Direct Injection Direct Injection Direct Injection
Cooling System Water Cooled Water Cooled Water Cooled Water Cooled Water Cooled
Lubrication Oil Capacity (lt) 7.3 11 11 11 11
Coolant Capacity (lt) 12.9 17 17 17 17
Fuel Tank Capacity (lt) 132 180 180 180 180
Fuel 100% of Prime Power 11.9 14.5 14.5 18.6 18.6
Consumption 75% of Prime Power 8.9 11 11 13.7 13.7
lt / h
50% of Prime Power 6 7.7 7.7 9.4 9.4
ALTERNATOR
Output Voltage (V) 400/230
Power Factor 0.8
Number of Poles 4
Frequency (Hz) 50
Voltage Regulation ±%0,5
Connection Type Star
DIMENSIONS & WEIGHT
Canopy Dimensions mm (WxDxH) 1050x2300x1715 1050x2700x1875 1050x2700x1875 1050x2700x1875 1050x2700x1875
Canopy Weight kg 960 1350 1350 1400 1400
Open Dimensions mm (WxDxH) 1050x1750x1450 1050x2090x1650 1050x2090x1650 1050x2090x1650 1000x2090x1650
Open Weight kg 765 1050 1050 1100 1100

Aytemiz-Makelsan reserves the right to make changes in model, specification, color, equipment and accessories without prior notice.
N/A: These dimensions and weights may change depending upon the characteristics of the project.
